DIN 127 SPRING LOCK WASHER

75

Advantages

  • Prevents loosening of fasteners due to vibration

  • Maintains tension in bolted joints

  • Simple and easy to install

  • Improves overall joint reliability

  • Cost effective locking solution

Applications

  • Used in automotive assemblies

  • Suitable for machinery and equipment

  • Applied in electrical panels and fittings

  • Used in construction and fabrication work

  • Common in industrial fastening systems

Send Enquiry

PRODUCT SPECIFICATION

d1 Used For d2 b s
2.1 M2 4.4 0.9 0.5
2.4 M2.3 4.9 1 0.6
2.6 M2.5 5.1 1 0.6
3.1 M3 6.2 1.3 0.8
3.6 M3.5 6.7 1.3 0.8
4.1 M4 7.6 1.5 .09
5.1 M5 9.2 1.8 1.2
6.1  M 6 11.8 2.5 1.6
7.1 M7 12.8 2.5 1.6
8.1 M8 14.8 3 2
10.2 M10 21.1 3.5 2.2
12.2 M12 21.1 4 2.5
14.2 M14 24.1 4.5 3
16.2 M16 24.1 5 3.5
18.2 M18 29.4 5 3.5
20.2 M20 33.6 6 4
22.5 M22 33.9 6 4
24.5 M24 40 7 5
27.5 M27 43 7 5
30.5 M30 48.2 8 6
33.5 M33 55.2 10 6
36.5 M36 58.2 10 6
39 M38 61.2 10 6
42.5 M42 68.2 12 7
45.5 M45 71.2 12 7
49 M48 75 12 7
53 M52 83 14 8
57 M56 87 14 8
