UNIQUE HIT ANCHOR
ADVANTAGES
• Deformation controlled anchor
with less displacement (Load – dis
placement curve similar to adhesive type
anchors).
• Easy installations.
• Through fixing and series installation.
• Yellow passivated or sheradised to ensure
optimum protection against corrosion.
• Also available in stainless-steel.
APPLICATIONS
• Timber to concrete : Form work, battens
and bottom plates.
• Services: Duct work, Pipes brackets, cable
trays.
• Metal work: Signs, hand rails and gates.
PRODUCT SPECIFICATION
| Ref. | Anchor size
(mm) |
Anchor length (mm) | Drill dia
(mm) |
Holding Power (mm) | Packing |
| CZA | M6 | 40
50 |
6
6 |
0.50
0.75 |
200 |
| CZA | M8 | 40 50
60 75 100 |
8
8 8 8 8 |
0.75
1.00 1.50 1.75 2.00 |
1000 |
| CZA | M10 | 50
75 100 125 |
10
10 10 10 |
1.50
1.75 2.00 2.50 |
50 |
| CZA | M12 | 60
75 100 150 |
12
12 12 12 |
2.50
2.75 3.00 3.50 |
50 |
| CZA | M14 | 100
125 150 |
14
14 14 |
3.00
3.50 3.75 |
25 |
| CZA | M16 | 75
100 125 150 175 200 |
16
16 16 16 16 16 |
3.50
3.70 4.00 4.50 4.75 |
20 |
| CZA | M20 | 150 200 | 20
20 |
5.00
6.00 |
10 |
| CZA | M22 | 160 | 22 | 7.00 | 10 |
| CZA | M24 | 175 200 | 24
24 |
8.00
8.50 |
10 |
