UNIQUE RAWL BOLT
ADVANTAGES
• Installing heavy equipment and machinery.
• Fixing balustrade, barriers, roller shutter doors, fire
doors and switchgear.
• Securing structural fixtures.
• Optimum taper nut angle for maximum expansion
in all substrates.
• Shield available seperately.
APPLICATIONS
• Ideal for overhead and ceiling work or heavy items.
• Securing cable trays. Ducting and trunking.
• Installing partition sand structural fixtures.
• For use in Roller shutter doors.
• For use in Fire doors.
• For use in Steel work.
PRODUCT SPECIFICATION
Bolt Size | Bolt Length | Fixture Thickness | Hole Diameter | Minimum Hole Depth | Packing |
[mm] | [mm] | [mm] | [mm] | pcs | |
M6 | 55 | 10 | 12 | 50 | 50 |
70 | 25 | ||||
85 | 40 | ||||
M8 | 65 | 10 | 14 | 55 | 50 |
80 | 25 | ||||
95 | 40 | ||||
M10 | 75 | 10 | 16 | 65 | 50 |
90 | 25 | ||||
115 | 50 | ||||
140 | 75 | ||||
M12 | 90 | 15 | 20 | 85 | 25 |
105 | 25 | ||||
120 | 40 | ||||
140 | 60 | ||||
M16 | 135 | 15 | 25 | 125 | 10 |
150 | 30 | ||||
180 | 60 | ||||
M20 | 195 | 60 | 32 | 140 | 10 |
235 | 100 | ||||
M24 | 255 | 100 | 38 | 160 | 5 |
